PLL620-00

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991

www.phaselink.com Rev 09/03/04 Page 2

FREQUENCY SELECTION TABLE

SEL3

(Pad #28)

SEL2

(Pad #29)

SEL1

(Pad #19)

SEL0

(Pad #20)

Selected Multiplier

1

0

1

1

Fin x 4

1

1

1

0

Fin x 2

1

1

1

1

No multiplication (no PLL)

All pads have internal pull-ups (default value is 1). Bond to GND to set to 0.

ELECTRICAL SPECIFICATIONS

1. Absolute Maximum Ratings

PARAMETERS

SYMBOL

MIN.

MAX.

UNITS

Supply Voltage

4.6

V

Input Voltage, dc

-0.5

V

Output Voltage, dc

-0.5

V

Storage Temperature

-65

150

°C

Ambient Operating Temperature*

-40

85

°C

Junction Temperature

125

°C

Lead Temperature (soldering, 10s)

260

°C

ESD Protection, Human Body Model

2

kV

Exposure of the device under conditions beyond the limits specified by Maximum Ratings for extended periods may cause permanent damage to the

device and affect product reliability. These conditions represent a stress rating only, and functional operations of the device at these or any other

conditions above the operational limits noted in this specification is not implied.

*

Note: Operating Temperature is guaranteed by design for all parts (COMMERCIAL and INDUSTRIAL), but tested for COMMERCIAL grade only.

2. Crystal Specifications

3. General Electrical Specifications

PARAMETERS

SYMBOL

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Supply Current (Loaded

Outputs)

PECL/LVDS/CMOS

100/80/40

mA

Operating Voltage

2.97

3.63

V

Output Clock Duty Cycle

@ 1.25V (LVDS)

45

45

45

50

50

50

55

55

55

%

Short Circuit Current

±50

mA

NAME

SYMBOL

CONDITIONS

MIN

MAX

UNITS

Parallel Resonant mode

N/A

Load capacitance (capacitance on

built-in on die seen by crystal)

Die only, no bond wire,

no package

3.2

pF

Inter-electrode capacitance

2

pF

Oscillation Frequency

100

200

MHz
