background image
Data Sheet
ADL5566
Rev. C | Page 5 of 24
Test Conditions/
3.3 V
5 V
Parameter
Comments
Min
Typ
Max
Min
Typ
Max
Unit
1000 MHz
Second/Third Harmonic
Distortion (HD2/HD3)
AV = 16 dB, RL = 200 Ω,
VOUT = 2 V p-p
−57.6/−43
−57.1/−45.9
dBc
Output IP3/Third-Order
Intermodulation
Distortion (OIP3/IMD3)
AV = 16 dB, RL = 200 Ω,
VOUT = 2 V p-p composite
(2 MHz spacing)
+23.2/−49.4
+24.8/−52.6
dBm/dBc
Output IP2 Second-Order
Intermodulation
Distortion (OIP2/IMD2)
AV = 16 dB, RL = 200 Ω,
VOUT = 2 V p-p composite
(2 MHz spacing)
+56.1/−57.4
+55.9/−57.2
dBm/dBc
Noise Spectral Density,
RTI (NSD)
AV = 16 dB
1.93
1.99
nV/√Hz
Noise Figure (NF)
AV = 16 dB
9.45
9.66
dB
