Data Sheet
ADL5566
Rev. C | Page 13 of 24
–100
–95
–90
–85
–80
–75
–70
–65
–60
–55
–50
–45
–40
–35
–30
–25
–20
–15
–10
–5
0
10M
100M
1G
10G
FREQUENCY (Hz)
Figure 33. Output Referred Crosstalk, Channel A to Channel B, VPOS = 3.3 V,
VCOM = 1.65 V
60
65
70
75
80
85
–40
–20
0
20
40
60
80
100
TEMPERATURE (°C)
5V
3.3V
Figure 34. ISUPPLY vs. Temperature, RL = 200 Ω, VPOS = 3.3 V and VPOS = 5 V
