PLL650-05

Low EMI Network LAN Clock

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 09/03/04 Page 4

Electrical Specifications

1. Absolute Maximum Ratings

PARAMETERS

SYMBOL

MIN.

MAX.

UNITS

Supply Voltage

4.6

V

Input Voltage, dc

-0.5

V

Output Voltage, dc

-0.5

V

Storage Temperature

-65

150

°C

Ambient Operating Temperature*

-40

85

°C

Junction Temperature

125

°C

Lead Temperature (soldering, 10s)

260

°C

ESD Protection, Human Body Model

2

kV

Exposure of the device under conditions beyond the limits specified by Maximum Ratings for extended periods may cause permanent damage to the device

and affect product reliability. These conditions represent a stress rating only, and functional operations of the device at these or any other conditions above

the operational limits noted in this specification is not implied.

* Note: Operating Temperature is guaranteed by design for all parts (COMMERCIAL and INDUSTRIAL), but tested for COMMERCIAL grade only.

2. AC Specifications

PARAMETERS

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Input Frequency

10

25

27

MHz

Output Rise Time

0.8V to 2.0V with no load

1.5

ns

Output Fall Time

2.0V to 0.8V with no load

1.5

ns

Duty Cycle*

45

50

55

%

Max. Absolute Jitter

Short term

±150

ps

Max. Jitter, cycle to cycle

80

ps

* : in case SDRAM output is selected to be 83.3MHz, the duty cycle of output pin 22 will be 40%-60% if its output frequency is selected to be 105MHz

(FS2=1). In all other situations, pin 22 will also have a 50%-50% typical duty cycle.
