Data Sheet
ADL6317
Rev. B | Page 13 of 38
0
–5
–10
–15
–20
–25
–30
1.4
1.6
1.8
2.0
FREQUENCY (GHz)
2.2
2.4
2.6
2.8
3.0
Figure 36. Return Loss of Single-Ended RF Output S22 from 1.5 GHz to 3 GHz
150
155
160
165
170
175
180
185
190
195
200
205
210
215
220
225
230
235
240
245
250
FREQUENCY (MHz)
AMPLIFIER 2 CURRENT
AMPLIFIER 1 CURRENT
TC = +105°C
TC = +40°C
TC = –20°C
Figure 37. Amplifier 1 and Amplifier 2 Supply Current vs. Frequency for
Various Temperatures
