B.2 How to install and configure a modem data connection over

USB

This example describes how to install and configure a data connection on a PC with the Windows 7

operating system using the TCP/IP stack of the PC, over the native USB interface of the SARA-R410M

and SARA-R412M modules connected to the Windows PC by the Cellular Native USB connector

(J105 on the ADP).

1.

Follow the board setup instructions in section 1.10 to provide the required connections with the

EVK-R4.

2.

Select: “Control Panel > Network

and Internet > Network and

Sharing Center > Setup a new

connection

or

network”

This

opens

the

“Choose

a

connection option” Wizard.

3.

Select Set up a dial-up connection. Click

on Next.
