New Product

Redundancy Unit

S8VK-R

Contribute to build high reliable systems

Compact and Cost-effective solution

for Back-up applications

Easy setup for system reliability

requirement

• Redundancy operating LED for the status confirmation

• A signal output for failure detection of power supplies

• By adjusting the power supply voltage to light up Balance LED,

the lifetime of power supplies will be more than twice.

*1

• Wide range input

DC5-30V (S8VK-R10), DC10-60V (S8VK-R20)

• Wide operation temperature range: -40 to 70 °C

• Safety standards:

UL508/60950-1, CSA C22.2 No. 107.1/60950-1

EN50178, EN60950-1 Lloyd's standards

*2

• EMS: EN61000-6-2

EMI: EN61000-6-3

•

5 year warranty *3

*1. The lifetime will depend on the connected power supply.

Refer to Functions on page 5.

*2. Scheduled to obtain certification in September, 2013.

*3.

Model Number Structure

Model Number Legend

Note: Not all combinations are possible. Refer to List of Models in Ordering Information, below.

Ordering Information

Note: For details on normal stock models, contact your nearest OMRON representative.

!

Refer to Safety Precautions for All Power Supplies and Safety

Precautions on page 9.

Input voltage

Output current

Model number

DC5-30V

10 A

S8VK-R10

DC10-60V

20 A

S8VK-R20

1

S8VK-R

@@

1. Output current

10: 10 A

20: 20 A
