S8VK-R

2

Specifications

Ratings, Characteristics, and Functions

* Scheduled to obtain certification in September, 2013.

Item

Output Current

10 A

20 A

Input

Voltage

5 to 30 VDC

10 to 60 VDC

Current

2x 0 to 5 A

2x 0 to 10 A

1x 0 to 10 A

1x 0 to 20 A

Output

Current

Continuous

10 A

20 A

Power Boost

12 A (Refer to Engineering Data)

24 A (Refer to Engineering Data)

Voltage

drop

Input to Output

0.56 V typ. 2x5 A

0.63 V typ. 1x10 A

0.7 V max. (-40°C 1x10 A)

0.67 V typ. 2x10 A

0.78 V typ. 1x20 A

0.9 V max. (-40°C 1x20 A)

Power

losses

6.5 W 2x5 A

7.1 W 1x10 A

0.8 W 0 A

15.8 W 2x10 A

18.0 W 1x20 A

0.8 W 0 A

Additional

functions

REDUNDANCY

OK

Indicator

Lighting: Voltage difference between Vin1 and Vin2 is less than 2.4 V typ. (color: green)

Contact

Photo switch contact ON: Voltage difference between Vin1 and Vin2 is less than 2.4 V typ.

Contact Ratings: 30 VDC, 50 mA

BALANCE

Indicator

Lighting: Voltage difference between Vin1 and Vin2 is less than 50 mV typ. (color: green)

Others

Ambient operating temperature

-40 to 70°C (Refer to Engineering Data)

Storage temperature

-40 to 85°C

Ambient operating humidity

0% to 95% (Storage humidity: 0% to 95%)

Dielectric strength

(detection current: 20 mA)

1.0 kVAC for 1 min. (between all inputs outputs and

terminal)

0.5 kVAC for 1 min. (between all inputs outputs and Signal contact)

Vibration resistance

10 to 55 Hz, 0.375-mm single amplitude for 2 h each in X, Y, and Z directions

10 to 150 Hz, 0.35-mm single amplitude (5 G max.) for 80 min each in X, Y, and Z directions

Shock resistance

EMI

Conducted

Emission

Conforms to EN61204-3 EN55011 Class B and based on FCC Class B

Radiated

Emission

Conforms to EN61204-3 EN55011 Class B

EMS

Conforms to EN61000-6-2

Approved Standards

UL Listed: UL508 (Listing)

UL UR: UL60950-1 (Recognition)

cUL: CSA C22.2 No.107.1

cUR: CSA C22.2 No.60950-1

EN: EN50178, EN60950-1

Lloyd's standards

*

Degree of protection

IP20 by EN/IEC60529

Weight

183 g

462 g
