Datasheet

ANT-W63-MON-ccc

Radiation Efficiency

Radiation efficiency (Figure 29), shows the ratio of power delivered to the antenna relative to the power

radiated at the antenna, expressed as a percentage, where a higher percentage indicates better

performance at a given frequency.

0

10

20

30

40

50

60

70

80

90

100

2400 2700 3000 3300 3600 3900 4200 4500 4800 5100 5400 5700 6000 6300 6600 6900 7200

Frequency (MHz)

Figure 29. ANT-W63-MON Antenna Efficiency, Straight

Average Gain

Average gain (Figure 28), is the average of all antenna gain in 3-dimensional space at each frequency,

providing an indication of overall performance without expressing antenna directionality.

-20

-15

-10

-5

0

5

10

2400 2700 3000 3300 3600 3900 4200 4500 4800 5100 5400 5700 6000 6300 6600 6900 7200

Frequency (MHz)

Figure 28. ANT-W63-MON Antenna Average Gain, Straight
