background image
AD8422
Data Sheet
Rev. B | Page 20 of 27
20mV/DIV
10µs/DIV
Figure 53. Small Signal Pulse Response (G = 100), RL = 2 kΩ, CL = 100 pF
20mV/DIV
100µs/DIV
Figure 54. Small Signal Pulse Response (G = 1000), RL = 2 kΩ, CL = 100 pF
50mV/DIV
10µs/DIV
NO LOAD
20 pF
50 pF
100 pF
Figure 55. Small Signal Pulse Response with Various Capacitive Loads
(G = 1), RL = No Load
