47 / 59 page ![]() Data Sheet ADA4254 Rev. B | Page 47 of 59 GPIO DATA REGISTER (GPIO_DATA) DETAILS Table 18. GPIO_DATA Register Details (Register 0x05) Bit Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Reserved GPIO_DATA[6:0] Access Reserved RW Reset Reserved 0 0 0 0 0 0 0 Bits[6:0], GPIO_DATA[6:0]—GPIO Data Values When a GPIO pin is configured as an output, writing a 1 to the corresponding GPIO_DATA bit causes that GPIO pin to output a logic high. Conversely, writing a 0 to the corresponding GPIO_DATA bit causes that GPIO pin to output a logic low. When a GPIO pin is configured as an input, each GPIO_DATA bit indicates whether the voltage on the corresponding GPIO pin is a logic high or logic low. Reading a 1 indicates a logic high. Reading a 0 indicates a logic low. Writing to the GPIO_DATA bits that are configured as inputs has no effect. |
|
