Fanless Embedded Box PCs

ARK-R Extended Modules

Specifications

General

PoE

8 x 10/100/1000Base T(X) PoE+, 802.3at compliant, Total: 60W

PoE Connector

M12 X-coded, 8PIN

Drive bay

1 x Removable 2.5" drive bay

Mechanical

Dimension

260 x 26.5 x 160.2

Environment

Operating temperature

-40 ~ 70 °C, EN50155 TX

Shock/Vibration

IEC61373 Category1, Class B

Ordering Information

P/N

Description

AMK-R100E

8 x GbE PoE M12 X-coded, 1 x removable 2.5" drive bay

Specifications

General

PoE

8 x 10/100 Base T(X) PoE+, 802.3at compliant, Total: 60W

PoE Connector

M12 D-coded, 4PIN

Drive bay

1 x Removable 2.5” drive bay

Mechanical

Dimension

260 x 26.5 x 140

Environment

Operating temperature

-40 ~ 70 °C, EN50155 TX

Shock/Vibration

IEC61373 Category1, Class B

Ordering Information

P/N

Description

AMK-R104E

8 x 10/100 Mbps PoE M12 D-Coded, 1 x removable 2.5" drive bay

Specifications

General

PoE

4 x 10/100/1000Base T(X) PoE+, 802.3at compliant, Total: 60W

PoE Connector

M12 X-coded, 8PIN

Drive bay

1 x Removable 2.5" drive bay

Mechanical

Dimension

260 x 26.5 x 160.2

Environment

Operating temperature

-40 ~ 70 °C, EN50155 TX

Shock/Vibration

IEC61373 Category1, Class B

Ordering Information

P/N

Description

AMK-R101E

4 x GbE PoE M12 X-coded, 1 x removable 2.5" drive bay

Specifications

General

PoE

4 x 10/100 Base T(X) PoE+, 802.3at compliant, Total: 60W

PoE Connector

M12 D-coded, 4PIN

Drive bay

1 x Removable 2.5” drive bay

Mechanical

Dimension

260 x 26.5 x 140

Environment

Operating temperature

-40 ~ 70 °C, EN50155 TX

Shock/Vibration

IEC61373 Category1, Class B

Ordering Information

P/N

Description

AMK-R105E

4 x 10/100 Mbps PoE M12 D-Coded, 1 x removable 2.5" drive bay

ARK-2231R+AMK-R100E

Extra 8 x GbE PoE + removable 2.5" drive bay

ARK-2231R+AMK-R104E

Extra 8 x 10/100 Mbps PoE + removable 2.5" drive bay

ARK-2231R+AMK-R101E

Extra 4 x GbE PoE + removable 2.5" drive bay

ARK-2231R+AMK-R105E

Extra 4 x 10/100 Mbps PoE + removable 2.5" drive bay

Note: When installing PoE extension modules with ARK-2231R, please check ordering information or contact us for details.
