CC1070

SWRS043

Page 56 of 58

27 General Information

Document Revision History

Revision

Date

Description/Changes

1.0

2003-10-30

Initial release.

1.1

2005-02-09

The various sections have been reorganized to improve readability

Added chapter numbering

Reorganized electrical specification section

Electrical specifications updated

Changed “channel width” to “channel spacing”

Changes to current consumption figures in TX mode and crystal

oscillator, bias and synthesizer mode

Included data on PA_EN pin drive

Included data on PLL lock time

Included data on PLL turn-on time

Updates to section on output power programming

Updates to section on output matching

Updates to section on VCO and PLL self-calibration

Updates to section on VCO, charge pump and PLL loop filter

New bill of materials for operation at 433 MHz and 868/915 MHz

Added recommended PCB footprint for package (QFN 20)

Added list of abbreviations

Changes to ordering information

1.2

2005-10-20

Calibration routine flow chart changed

Added chapter on TX data latency

1.3

2006-02-01

Updates to Ordering Information and Address Information.

The lowest supply voltage has been changed from 2.1 V to 2.3 V

Product Status Definitions

Data Sheet Identification

Product Status

Definition

Advance Information

Planned or Under

Development

This data sheet contains the design specifications for

product development. Specifications may change in

any manner without notice.

Preliminary

Engineering Samples

and First Production

This data sheet contains preliminary data, and

supplementary data will be published at a later date.

Chipcon reserves the right to make changes at any

time without notice in order to improve design and

supply the best possible product.

No Identification Noted

Full Production

This data sheet contains the final specifications.

Chipcon reserves the right to make changes at any

time without notice in order to improve design and

supply the best possible product.

Obsolete

Not In Production

This data sheet contains specifications on a product

that has been discontinued by Chipcon. The data

sheet is printed for reference information only.
