CC1070

SWRS043

Page 1 of 58

CC1070 Single Chip Low Power RF Transmitter for Narrowband Systems

Applications

• Narrowband low power UHF wireless

data transmitters

• 402 / 424 / 426 / 429 / 433 / 447 / 449 /

469 /

868 and 915 MHz ISM/SRD

band systems

• TPMS – Tire Pressure Monitoring

Systems

• AMR – Automatic Meter Reading

• Wireless alarm and security systems

• Home automation

• Low power telemetry

Product Description

CC1070 is a true single-chip UHF

transmitter designed for very low power

and very low voltage wireless applications.

The circuit is mainly intended for the ISM

(Industrial, Scientific and Medical) and

SRD (Short Range Device) frequency

bands at 402, 424, 426, 429, 433, 447,

449, 469, 868 and 915 MHz, but can

easily be programmed for multi-channel

operation at other frequencies in the 402 -

470 and 804 - 940 MHz range.

The

CC1070 is especially suited for narrow-

band systems with channel spacings of

12.5 or 25 kHz complying with ARIB STD

T-67 and EN 300 220.

The

CC1070 main operating parameters

can be programmed via a serial bus, thus

making

CC1070 a very flexible and easy to

use transmitter. In a typical application

CC1070 will be used together with a

microcontroller and a few external passive

components.

CC1070 is based on Chipcon’s SmartRF® -

02 technology in 0.35

µm CMOS.

Features

• True single chip UHF RF transmitter

• Frequency range 402 - 470 MHz and

804 - 940 MHz

• Programmable output power

• Low supply voltage (2.3 to 3.6 V)

• Very few external components required

• Small size (QFN 20 package)

• Pb-free package

• Data rate up to 153.6 kBaud

• OOK, FSK and GFSK data modulation

• Fully on-chip VCO

• Programmable

frequency

makes

crystal temperature drift compensation

possible without TCXO

• Suitable for frequency hopping systems

• Suited

for

systems

targeting

compliance with EN 300 220, FCC

CFR47 part 15 and ARIB STD T-67

• Development kit available

• Easy-to-use software for generating the

CC1070 configuration data
