1 / 21 page

www.sensirion.com

Version 1 – March 2022

1/21

▪

Large supply voltage range: 2.4 – 5.5 V

▪

Accuracy: ± 75 ppm @ 400 ppm – 1’000 ppm

▪

Digital I2C interface

▪

Integrated temperature and humidity sensor

SCD42

Breaking the size barrier in CO2 sensing

Products

Details

SCD42-D-R2 Accuracy: ± 75 ppm @ 400 – 1’000 ppm

Full product list on page 20

Functional Block Diagram

Device Overview

Product Summary

The SCD42 is Sensirion’s next generation miniature CO2

sensor. This sensor builds on the photoacoustic sensing

principle and Sensirion’s patented PAsens® and

CMOSens® technology to offer high accuracy at an

unmatched price and smallest form factor. SMD assembly

allows cost- and space-effective integration of the sensor

combined with maximal freedom of design. On-chip signal

compensation is realized with the build-in SHT4x humidity

and temperature sensor.

CO2 is a key indicator for indoor air quality as high levels

compromise humans’ cognitive performance and well-

being. The SCD42 enables smart ventilation systems to

regulate ventilation in the most energy-efficient and

human-friendly way. Moreover, indoor air quality monitors

and other connected devices based on the SCD42 can

help maintaining low CO2 concentration for a healthy,

productive environment.

Features

▪

Photoacoustic sensor technology PASens®

▪

Smallest form factor: 10.1 x 10.1 x 6.5 mm3

▪

Reflow solderable for cost effective assembly

▪

Large output range: 0 ppm – 40’000 ppm
