HANBit

HFDOM40KRxxx

URL:www.hbe.co.kr

22 / 22

HANBit Electronics Co., Ltd.

Rev. 1.2 (Decemver. 2003)

18h

Corrected ECC Error

05h , 30-34h , 37h ,3Eh

Self Test or Diagnostic Failed

10h , 14h

ID Not Found

3Ah

Spare Sectors Exhausted

1Fh

Data Transfer Error / Aborted Command

0Ch , 38h , 3Bh , 3Ch , 3Fh

Corrupted Media Format

03h

Write / Erase Failed

22h

Power Level 1 Disabled

Seek –7X h

Bit->

7

6

5

4

3

2

1

0

Command(7)

7Xh

C/D/H(6)

1

LBA

1

Drive

Head(LBA 27 – 24)

Cyl High(5)

Cylinder High (LBA 23 – 16)

Cyl Low(4)

Cylinder Low (15 – 8)

Sec Num(3)

X (LBA 7 – 0)

Sec Cnt(2)

X

Feature(1)

X

Seek

This command is effectively a NOP command to the CompactFlash Storage Card although it does perform a range

check of cylinder and head or LBA address and returns an error if the address is out of range.

Set Features - EFh

Bit->

7

6

5

4

3

2

1

0

Command(7) EFh

C/D/H(6)

X

Drive

X

Cyl High(5)

X

Cyl Low(4)

X

Sec Num(3)

X

Sec Cnt(2)

Configure

Feature(1)

Feature

Set Features

This command is used by the host to establish or select certain features. Table 45 defines all features that are

supported.

Feature Supported

Feature

Operation

01h

Enable 8 – bit data transfers

0Ah

Enable Power Level 1 commands
