commands are disabled. At power on, or after a hardware or (unless disabled by a Set Feature command) software

reset, the default mode is Read and Write Multiple disabled.

Set Sleep Mode – 99h or E6h

Bit->

7

6

5

4

3

2

1

0

Command(7)

99h or E6h

C/D/H(6)

X

Drive

X

Cyl High(5)

X

Cyl Low(4)

X

Sec Num(3)

X

Sec Cnt(2)

X

Feature(1)

X

Set Sleep Mode

This command causes the CompactFlash Storage Card to set BSY, enter the Sleep mode, clear BSY and generate

an interrupt. Recovery from sleep mode is accomplished by simply issuing another command (a reset is permitted

but not required). Sleep mode is also entered when internal timer expires so the host does not need to issue this

command except when it wishes to enter Sleep mode immediately. The default value for the timer is 1.6

milliseconds. Note that this time base (1.6 msec) is different from the ATA Specification.

Standby – 96h or E2h

Bit->

7

6

5

4

3

2

1

0

Command(7)

96h or E2h

C/D/H(6)

X

Drive

X

Cyl High(5)

X

Cyl Low(4)

X

Sec Num(3)

X

Sec Cnt(2)

X

Feature(1)

X

Standby

This command causes the CompactFlash Storage Card to set BSY, enter the Sleep mode (which corresponds to

the ATA “Standby” Mode), clear BSY and return the interrupt immediately.

Recovery from sleep mode is accomplished by simply issuing another command (a reset is not required).

Standby Immediate – 94h or E0h

Bit->

7

6

5

4

3

2

1

0

Command(7)

94h or E0h

C/D/H(6)

X

Drive

X

Cyl High(5)

X

Cyl Low(4)

X

Sec Num(3)

X
