H7CC-A

Dimensions

(Unit: mm)

Counters

Dimensions with Flush Mounting Adapter

H7CC-A/-AS/-AW/-AWS/-AWD/-AWSD/-AU/-AUD (Flush Mounting Models)

Note: M3.5 terminal screw (effective length: 6 mm)

44.8

u 44.8

u 48

H7CC-A8/-A8D (Flush Mounting/Surface Mounting Models)

44.8

u 44.8

u 48

63.7

14.4

H7CC-A11/-A11S/-A11D/-A11SD (Flush Mounting/Surface Mounting Models)

63.7

14.4

44.8

u 44.8

u 48

57.5

7.5

(51)

H7CC-A/-AS/-AW/-AWS/-AWD/-AWSD/-AU/-AUD

(Provided with Adapter and Waterproof packing)

Panel Cutouts

Panel cutouts are as shown below. (according to

DIN43700).

Note: 1. The mounting panel thickness should be

1 to 5 mm.

2. To allow easier operation, it is

recommended that Adapters be mounted

so that the gap between sides with hooks

is at least 15 mm (i.e., with the panel

cutouts separated by at least 60 mm).

3. It is possible to horizontally mount Timers

side by side. Attach the Flush Mounting

Adapters so that the surfaces without

hooks are on the sides of the Timers. If

they are mounted side-by-side, water-

resistance will be lost.

60 min.

15 min.

+0.6

With Y92A-48F1 attached.

With Y92A-48 attached.

A=(48n

−2.5)

−0

A=(51n

−5.5) +1

−0

A={48n

−2.5+(n−1)×4} +1

−0

n Units mounted

side by side

7.5

89.9

(51)

H7CC-A8/-A8D/-A11/-A11S/-A11D/-A11SD

(Flush Mounting/Surface Mounting Models)

(Adapter and Waterproof packing Ordered Separately)
