PI2DPX2020
29
www.diodes.com
July 2022
Diodes Incorporated
PI2DPX2020
Document Number DS43506 Rev 5-2
BYTE 11 (Reserved)
Bit
Type
Power-up Condition
Comment
7
R/W
1
Reserved
6
R/W
1
5
R/W
1
4
R/W
1
3
R/W
1
2
R/W
1
1
R/W
0
0
R/W
0
BYTE 12 (Reserved)
Bit
Type
Power-up Condition
Comment
7
R/W
0
Reserved
6
R/W
0
5
R/W
1
4
R/W
1
3
R/W
0
2
R/W
0
1
R/W
0
0
R/W
1
BYTE 13 (Power State of the Channel CON0/1)
Bit
Type
Power-up Condition
Control Affected
Comment
7
RO
0
CON0_State<2>
For the channel operating mode
000 – PD (Power down mode)
001 – PowerON (Power on ramping mode)
010 – UPM_Short (UPM less than 328ms)
011 – UPM_Long (UPM more than 328ms)
100 - UPM_Active (Unplug active mode)
101 - DSM (U1/U2/U3 power saving mode)
110 – SM (Slumber Mode)
111 - AM (active mode)
6
RO
0
CON0_State<1>
5
RO
0
CON0_State<0>
4
RO
0
Reserved
3
RO
0
CON1_State<2>
2
RO
0
CON1_State<1>
1
RO
0
CON1_State<0>
0
RO
0
Reserved
