background image
A Product Line of
Diodes Incorporated
PI2DPX2020
31
www.diodes.com
July 2022
Diodes Incorporated
PI2DPX2020
Document Number DS43506 Rev 5-2
BYTE 16 (AUX and HPD Monitor)
Bit
Type
Power-up Condition
Comment
7
RO
1
Reserved
6
RO
1
Reserved
5
RO
0
AUX_IDLE_DET#
Detect the AUX activities
“0” – Idle
“1” – has activities
4
RO
1
DP_HPD
The condition of IN_HPD
0 – De-asserted
1 – Asserted
Notes: When DP_HPD_PIN_EN#=1, then, this value is 1 always.
3
RO
1
AP0_RX_SEL
“0” AP0 is TX terminal. “1” AP0 is RX terminal
2
RO
1
AP3_RX_SEL
“0” AP3 is TX terminal. “1” AP3 is RX terminal
1
RO
0
CON0_RX_SEL
“0” CON0 is TX terminal. “1” CON0 is RX terminal
0
RO
0
CON3_RX_SEL
“0” CON3 is TX terminal. “1” CON3 is RX terminal
BYTE 17
Bit
Type
Power-up Condition
Comment
7
RO
0
Reserved
6
RO
0
5
RO
0
4
RO
1
3
RO
0
2
RO
1
1
RO
0
0
RO
0
