FT900

/1/2/3 Revision C Embedded Microcontroller Datasheet

Version 1.0

Document No. BRT_000172 Clearance No.: BRT#087

Devices Characteristics and Ratings

5.1

Absolute Maximum Ratings

The absolute maximum ratings for the FT900/1/2/3 series devices are as follows. These are in

accordance with the Absolute Maximum Rating System (IEC 60134). Exceeding these may cause

permanent damage to the device.

Parameter

Value

Unit

Storage Temperature

-65 to +150

°C

Floor Life (Out of Bag) At Factory Ambient

(30°C / 60% Relative Humidity)

168 Hours

(IPC/JEDEC J-STD-033A MSL Level 3

Compliant)*

Hours

Ambient Temperature (Power Applied)

-40 to +85

°C

VCC3V3 Supply Voltage

-0.5 to +4.6

DC Input Voltage – Host H_DP and H_DM

-0.5 to +5

DC Input Voltage – Peripheral D_DP and

D_DM

-0.5 to +5

DC Input Voltage – Ethernet TXON, TXOP,

RXIN and RXIP

-0.5 to +5.6

DC Input Voltage – 5V tolerance I/O cells

-0.5 to +5.8

Others (ADC, DAC) – 3V I/O cells

-0.5 to VCC3V3+0.5

Table 5-1 - Absolute Maximum Ratings

Note: If devices are stored out of the packaging beyond this time limit the devices should be baked

before use. The devices should be ramped up to a temperature of +125°C and baked for up to 17 hours.
