6 / 251 page  5 Device Comparison Table 5-1 shows the features of the SoC. Table 5-1. Device Comparison FEATURES(6) REFERENCE NAME TDA4VE88 TDA4AL88 TDA4VL21 PROCESSORS AND ACCELERATORS Speed Grades T, N T, N H Arm Cortex-A72 Microprocessor Subsystem Arm A72 Dual Core Dual Core Dual Core Arm Cortex-R5F Arm R5F Hexa Core Quad Core Quad Core Lockstep Optional(1) Optional(1) Optional(1) Security Management Subsystem SMS Yes Yes Yes Security Accelerators SA Yes Yes Yes C7x Floating Point, Vector DSP C7x DSP Dual Core Dual Core Dual Core Deep Learning Accelerator MMA Yes Yes Yes Graphics Accelerator IMG BXS-64-4 GPU Yes No Yes Depth and Motion Processing Accelerators DMPAC Yes Yes Yes Vision Processing Accelerators VPAC Yes Yes Yes Video Encoder/Decoder VENC/VDEC Enc/Dec Enc only Enc/Dec SAFETY AND SECURITY Safety Targeted Safety Optional(1) Optional(1) Optional(1) Device Security Security Optional(2) Optional(2) Optional(2) AEC-Q100 Qualified Q1 Optional(3) Optional(3) Optional(3) PROGRAM AND DATA STORAGE On-Chip Shared Memory (RAM) in MAIN Domain OCSRAM 2x512KB SRAM 1x512KB SRAM 1x512KB SRAM On-Chip Shared Memory (RAM) in MCU Domain MCU_MSRAM 1MB SRAM 1MB SRAM 1MB SRAM Multicore Shared Memory Controller MSMC 4MB (On-Chip SRAM with ECC) 4MB (On-Chip SRAM with ECC) 4MB (On-Chip SRAM with ECC) LPDDR4 DDR Subsystem DDRSS0 Up to 8GB (32-bit data) with inline ECC Up to 8GB (32-bit data) with inline ECC Up to 8GB (32-bit data) with inline ECC DDRSS1 Up to 8GB (32-bit data) with inline ECC No(8) No(8) SECDED 7-Bit 7-Bit 7-Bit General-Purpose Memory Controller GPMC Up to 1GB with ECC Up to 1GB with ECC Up to 1GB with ECC PERIPHERALS Display Subsystem DSS Yes Yes Yes DSI 4L TX 2 1(10) 1(10) eDP 4L 1 0 1 DPI 1 1 1 Modular Controller Area Network Interface with Full CAN-FD Support MCAN 20 20 20 General-Purpose I/O GPIO 155 155 155 Inter-Integrated Circuit Interface I2C 10 10 10 Improved Inter-Integrated Circuit Interface I3C 1 1 1 Analog-to-Digital Converter ADC 2 2 2 Capture Subsystem with Camera Serial Interface (CSI2) CSI2.0 4L RX 2 2 2 CSI2.0 4L TX 2 2 2 Multichannel Serial Peripheral Interface MCSPI 11 11 11 TDA4VE-Q1, TDA4AL-Q1, TDA4VL-Q1 SPRSP62 – DECEMBER 2022 www.ti.com 6 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated Product Folder Links: TDA4VE-Q1 TDA4AL-Q1 TDA4VL-Q1 |
|
