9.1.1 Standard Package Symbolization

Note

Some devices may have a cosmetic circular marking visible on the top of the device package which

results from the production test process. In addition, some devices may also show a color variation in

the package substrate which results from the substrate manufacturer. These differences are cosmetic

only with no reliability impact.

J7ES_SPRSP35_PACK_01

xBBBBBBBBzYrPPPcQ1

PIN ONE INDICATOR

YYY

ZZZ

XXXXXXX

Figure 9-1. Printed Device Reference

www.ti.com

TDA4VE-Q1, TDA4AL-Q1, TDA4VL-Q1

SPRSP62 – DECEMBER 2022

Submit Document Feedback

241

Product Folder Links: TDA4VE-Q1 TDA4AL-Q1 TDA4VL-Q1
