KSZ9567R

DS00002329D-page 134

 2017-2019 Microchip Technology Inc.

5.2

Port Registers

This section details the device’s port registers. All settings are on a per-port basis. Address field “N” specifies the port

number. Valid values for “N” are 1 to 7 for some registers, 6 to 7 for MAC port specific registers, and 0 to 5 for PHY

specific registers.

For an overview of the device’s entire register map, refer to Section 5.0, "Device Registers". For details on the device’s

global registers, refer to Section 5.1, "Global Registers".

5.2.1

PORT N: PORT OPERATION CONTROL REGISTERS (0xN000 - 0xN0FF)

5.2.1.1

Port Default Tag 0 Register

5.2.1.2

Port Default Tag 1 Register

5.2.1.3

Port PME_WoL Event Register

Address:

0xN000

Port N: 1-7

Size:

8 bits

Bits

Description

Type

Default

7:0

Port Default 802.1Q Tag [15:8]

Bits [7:5]: Priority Code Point (PCP)

Bit [4]: Drop Eligible Indicator (DEI)

Bits [3:0]: VLAN Identifier (VID) [11:8]

R/W

0x00

Address:

0xN001

Port N: 1-7

Size:

8 bits

Bits

Description

Type

Default

7:0

Port Default 802.1Q tag [7:0]

VLAN Identifier (VID) [7:0]

R/W

0x01

Address:

0xN013

Port N: 1-7

Size:

8 bits

Bits

Description

Type

Default

7:3

RESERVED

0000_0b

Magic Packet Detect

To be detected, the destination address of the Magic Packet must match the

Global Switch MAC Address in the Switch MAC Address 0 Register through

Switch MAC Address 5 Register.

1 = Magic Packet is detected at this port

0 = Not detected

RO/WC
