 2017-2019 Microchip Technology Inc.

DS00002329D-page 17

KSZ9567R

RXD6_1

Port 6 MII/RMII Mode

0: MII: PHY Mode (Default)

RMII: Clock Mode. RMII 50MHz reference clock is output on REFCLKO6. (Default)

RGMII: No effect

1: MII: MAC Mode

RMII: Normal Mode. RMII 50MHz reference clock is input on REFCLKI6.

RGMII: No effect

RXD6_0

Port 6 Speed Select

0: 1000Mbps Mode (Default)

1: 100Mbps Mode

Note:

If Port 6 is configured for MII or RMII, set the speed to 100Mbps.

RXD7_3, RXD7_2

[RXD7_3, RXD7_2]: Port 7 Mode

00: RGMII (Default)

01: RMII

10: Reserved

11: MII

RXD7_1

Port 7 MII/RMII Mode

0: MII: PHY Mode (Default)

RMII: Clock Mode. RMII 50MHz reference clock is output on REFCLKO7. (Default)

RGMII: No effect

1: MII: MAC Mode

RMII: Normal Mode. RMII 50MHz reference clock is input on REFCLKI7.

RGMII: No effect

RXD7_0

Port 7 Speed Select

0: 1000Mbps Mode (Default)

1: 100Mbps Mode

Note:

If Port 7 is configured for MII or RMII, set the speed to 100Mbps.

RX_DV7/CRS_DV7/

RX_CTL7

In-Band Management

0: Disable In-Band Management (Default)

1: Enable In-Band Management

TABLE 3-3:

CONFIGURATION STRAP DESCRIPTIONS (CONTINUED)

CONFIGURATION

STRAP PIN

DESCRIPTION
