Functional overview

STM32U535xx

72/278

DS14217 Rev 1

•

16-bit ARR autoreload register

•

16-bit capture/compare register

•

Continuous/One-shot mode

•

Selectable software/hardware input trigger

•

Programmable digital glitch filter

•

Configurable output: pulse, PWM

•

Configurable I/O polarity

•

Encoder mode

•

Repetition counter

•

Up to 2 independent channels for:

–

Input capture

–

PWM generation (edge-aligned mode)

–

One-pulse mode output

•

Interrupt generation on 10 events

•

DMA request generation on the following events:

–

Update event

–

Input capture

3.36.5

Infrared interface (IRTIM)

An infrared interface (IRTIM) for remote control is available on the device. It can be used

with an infrared LED to perform remote control functions. It uses internal connections with

TIM16 and TIM17.

3.36.6

Independent watchdog (IWDG)

The independent watchdog is based on a 12-bit downcounter and a 8-bit prescaler. It is

clocked from an independent 32 kHz internal RC (LSI) and, as it operates independently

from the main clock, it can operate in Stop and Standby modes. It can be used either as

a watchdog to reset the device when a problem occurs, or as a free running timer for

application timeout management. It is hardware or software configurable through the option

bytes. The counter can be frozen in Debug mode.

3.36.7

Window watchdog (WWDG)

The window watchdog is based on a 7-bit downcounter that can be set as free running. It

can be used as a watchdog to reset the device when a problem occurs. It is clocked from

the main clock. It has an early warning interrupt capability and the counter can be frozen

in Debug mode.

3.36.8

SysTick timer

The Cortex-M33 with TrustZone embeds two SysTick timers.

When TrustZone is activated, two SysTick timer are available:

•

SysTick, secure instance

•

SysTick, nonsecure instance
