69 / 159 page ![]() DS13564 Rev 4 69/159 STM32G0C1xC/xE Electrical characteristics 124 5.3.2 Operating conditions at power-up / power-down The parameters given in Table 25 are derived from tests performed under the ambient temperature condition summarized in Table 24. 5.3.3 Embedded reset and power control block characteristics The parameters given in Table 26 are derived from tests performed under the ambient temperature conditions summarized in Table 24: General operating conditions. VDDA Analog supply voltage For ADC and COMP operation 1.62 3.6 V For DAC operation 1.8 3.6 For VREFBUF operation 2.4 3.6 VBAT Backup operating voltage - 1.55 3.6 V VIN I/O input voltage All except TT_xx and FT_c -0.3 Min(VDD + 3.6, 5.5)(2) V TT_xx -0.3 VDD + 0.3 FT_c -0.3 5.0(2) TA Ambient temperature(3) Suffix 6(4) -40 85 °C Suffix 7(4) -40 105 Suffix 3(4) -40 125 TJ Junction temperature Suffix 6(4) -40 105 °C Suffix 7(4) -40 125 Suffix 3(4) -40 130 1. When RESET is released functionality is guaranteed down to VPDR min. 2. For operation with voltage higher than VDD +0.3 V, the internal pull-up and pull-down resistors must be disabled. 3. The TA(max) applies to PD(max). At PD < PD(max) the ambient temperature is allowed to go higher than TA(max) provided that the junction temperature TJ does not exceed TJ(max). Refer to Section 6.11: Thermal characteristics. 4. Temperature range digit in the order code. See Section 7: Ordering information. Table 24. General operating conditions (continued) Symbol Parameter Conditions Min Max Unit Table 25. Operating conditions at power-up / power-down Symbol Parameter Conditions Min Max Unit tVDD VDD slew rate VDD rising - ∞ µs/V VDD falling; ULPEN = 0 10 ∞ VDD falling; ULPEN = 1 100 ∞ ms/V Table 26. Embedded reset and power control block characteristics Symbol Parameter Conditions(1) Min Typ Max Unit tRSTTEMPO(2) POR temporization when VDD crosses VPOR VDD rising - 250 400 μs VPOR(2) Power-on reset threshold - 1.62 1.66 1.70 V |
|
