background image
4.4
Recommended operating conditions
Table 5. Recommended operating conditions
Symbol
Parameter
Min.
Max. Unit
Remarks
VCC
VCC supply voltage
VCC-OFF
19
V
After device turn-on
VHV_op_1 HVSU voltage range CFG1, CFG3, CFG5 0
480
V
Linearity not guaranteed above 480 V
VHV_op_2 HVSU voltage range CFG2, CFG4
0
760
V
Linearity not guaranteed if VPK is lower than
200 V
VFB
FB pin regulation voltage range
0.3
2.8
V
VOPTO
OPTO pin regulation voltage range
VBM
2.8
V
VCS_op
CS pin operative condition
0
1.2
V
VZCD
ZCD pin operative voltage
Self-limited 3.3
V
DC condition, Isource < 1 mA RZCD = 22 kΩ to
47 kΩ
IZCD_src
ZCD pin operative source current
0
3
mA
During on-time
IZCD_snk
ZCD pin operative sink current
0
1
mA
During off-time
VVL
VL pin operative voltage
0
3.0
V
VFAULT
FAULT pin operating range
0
3.3
V
HVLED101
Recommended operating conditions
DS14143 - Rev 2
page 7/36
