ABSOLUTE MAXIMUM RATINGS

Supply Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.6 V

Input Voltage . . . . . . . . . . . . –0.3 V to +5.3 V (5 V Tolerant)

Output Voltage Swing . . . . . . . . . . –0.3 V to VDDIO + 0.3 V

Load Capacitance . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200 pF

Junction Temperature Under Bias . . . . . . . . . . . . . . . . 125

°C

Storage Temperature Range . . . . . . . . . . . . –65

°C to +150°C

Lead Temperature (5 sec) . . . . . . . . . . . . . . . . . . . . . . 280

°C

*Stresses greater than those listed above may cause permanent damage to the

device. These are stress ratings only; functional operation of the device at these or

any other conditions greater than those indicated in the operational sections of this

specification is not implied. Exposure to absolute maximum rating conditions for

extended periods may affect device reliability.

Thermal Characteristics

128-Lead Plastic Quad Flatpack:

JA = 41

°C/W, No Airflow

JA = 39

°C/W, 200 LFPM Airflow

JA = 37

°C/W, 400 LFPM Airflow

Thermal measurements made in the horizontal position on

a 4-layer board.

EXPLANATION OF TEST LEVELS

100% Production Tested.

II.

100% Production Tested at 25

°C, and Sample Tested at

Specified Temperatures.

III. Sample Tested Only.

IV. Parameter Guaranteed by Design and Analysis.

Parameter is Typical Value Only.

VI. 100% Production Tested at 25

°C, and Sample Tested at

Temperature Extremes.

CAUTION

ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily

accumulate on the human body and test equipment and can discharge without detection.

Although the AD6624 features proprietary ESD protection circuitry, permanent damage may

occur on devices subjected to high-energy electrostatic discharges. Therefore, proper ESD

precautions are recommended to avoid performance degradation or loss of functionality.

ORDERING GUIDE

Package

Model

Temperature Range

Package Description

Option

AD6624AS

–40

°C to +70°C (Ambient)

128-Lead MQFP (Plastic Quad Flatpack)

S-128-1

AD6624S/PCB

Evaluation Board with AD6624 and Software
