AD8336

Rev. 0 | Page 6 of 28

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltage (VPOS, VNEG)

±15 V

Input Voltage (INPP, INPN)

VPOS, VNEG

Gain Voltage (GPOS, GNEG)

VPOS, VNEG

PWRA

5 V, GND

Power Dissipation

VS ≤ ±5 V

0.43 W

±5 V < VS ≤ ±12 V

1.12 W

Operating Temperature Range

±3 V < VS ≤ ±10 V

–55°C to +125°C

±10 V < VS ≤ ±12 V

–55°C to +85°C

Storage Temperature Range

–65°C to +150°C

Lead Temperature (Soldering 60 sec)

300°C

Thermal Data (4-layer JEDEC board, no air

flow, exposed pad soldered to PC board)

θJA

58.2°C/W

θJB

35.9°C/W

θJC

9.2°C/W

ΨJT

1.1°C/W

ΨJB

34.5°C/W

Stresses above those listed under the Absolute Maximum

Ratings may cause permanent damage to the device. This is a

stress rating only; functional operation of the device at these or

any other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

ESD CAUTION
