E L E C T R O N I C S I N C .

Surface Mount Power Inductors

TEL: (818) 892-0761

FAX: (818) 894-5791

http://www.pca.com

PCA ELECTRONICS, INC.

16799 SCHOENBORN ST.

NORTH HILLS, CA 91343

EPI D8763 Series

Product performance is limited to specified parameters. Data is subject to change without prior notice.

Primary Specification

Unless Otherwise Specified Dimensions are in Inches /mm ± .010 /.25

CSIXXXXXXD8763

Rev. -

12/11/02

.78

1.5

2.2

3.3

3.9

4.7

6.0

7.8

Induct.

(µH ± 20%)

@ Rated Current

.0026

.004

.0061

.0086

.010

.014

.017

.018

.026

.032

DCR

(

Ω Max.)

EPI0L8303D8763

EPI1L5253D8763

EPI2L2203D8763

EPI3L3173D8763

EPI3L9153D8763

EPI4L7133D8763

EPI6L0123D8763

EPI7L8113D8763

EPI100103D8763

EPI150802D8763

Part

Number

I Sat

(Amp)

Package D8763

Notes :

1. Temperature Rise : 40°C Typ. @ I rms

2. Inductance Change at Isat: 10% Max.

9.0

8.4

7.5

6.0

4.4

I rms

(Amp)

Land Pattern

.125

(3.18)

.340

(8.64)

.815

(20.70)

.565

(14.35)

.315 Max.

(8.00)

Marking:

PCA

EPIXXXXXD8763

.640

Max.

(16.26)

.880 Max.

(22.35)

• Virtually no limit on V µSec as long as max. RMS Current Limit and

Temperature Rise Limit are not exceeded

• Low loss material ensures operation in high frequency switching

converters, such as Buck, Boost or as output averaging filter inductor

• Low cost Robust construction to withstand most SMT processes

• Also suitable for use in High Quality Filter Applications

• Low Profile version for High Current Applications

.78

1.5

2.2

3.3

3.9

4.7

6.0

7.8

Induct.

(µH ± 20%)

@ 0 Adc

• Operating Temperature : -40°C to +85°C •
