background image
CC2500
PRELIMINARY Data Sheet (Rev.1.2)
SWRS040A
Page 44 of 83
-10
-5
0
5
10
15
20
25
30
35
40
-1
-0.8
-0.6
-0.4
-0.2
0
0.2
0.4
0.6
0.8
1
Fre que ncy offse t [M Hz]
Figure 23: Typical selectivity at 10 kbps. IF frequency is 273.9 kHz.
MDMCFG2.DEM_DCFILT_OFF
= 1
-20
-10
0
10
20
30
40
50
-3
-2
-1
0
1
2
3
Fre que ncy offse t [MHz]
Figure 24: Typical selectivity at 250 kbps. IF frequency is 177.7 kHz.
MDMCFG2.DEM_DCFILT_OFF
= 0
-20
-10
0
10
20
30
40
50
-3
-2
-1
0
1
2
3
Fre que ncy offse t [MHz]
Figure 25: Typical selectivity at 250 kbps. IF frequency is 457 kHz.
MDMCFG2.DEM_DCFILT_OFF
= 1
