Datasheet

002-37178 Rev. *B

2023-10-10

EZ-PD™ PAG2S-PS integrated USB PD and

synchronous-rectification controller

Acronyms

7Acronyms

Table 11

Acronyms used in this document

Acronym

Description

ACF

active clamp flyback

ADC

analog-to-digital converter

Arm®

advanced RISC machine, a CPU architecture

BOD

brown out detect

BMC

biphase mark code

constant current

CCM

continuous conduction mode

CPU

central processing unit

CrCM

critical conduction mode

current sense

CSN

current sense negative

CSP

current sense positive

DCM

discontinuous conduction mode

DFP

downstream facing port

data plus

data minus

error amplifier

EMI

electromagnetic interference

EPR

extended power range

ESD

electrostatic discharge

feedback

full-speed

GPIO

general-purpose input/output

ILO

internal low-speed oscillator, see also IMO

IMO

internal main oscillator, see also ILO

I/O

input/output, see also GPIO

LSCSA

low-side current sense amplifier

LVTTL

low-voltage transistor-transistor logic

NMOS

N-type metal-oxide-semiconductor

OCP

overcurrent protection

OVP

overvoltage protection

Power Delivery

PHY

physical layer

POR

power-on reset

PPS

programmable power supply

PWM

pulse-width modulator
