277/429

I2C BUS INTERFACE

I2C BUS INTERFACE (Cont’d)

I2C CLOCK CONTROL REGISTER

(I2CCCR)

R243 - Read / Write

Reset Value: 0000 0000 (00h)

Bit 7 = FM/SM Fast/Standard I2C mode.

This bit is used to select between fast and stand-

ard mode. See the description of the following bits.

It is set and cleared by software. It is not cleared

when the peripheral is disabled (I2CCR.PE=0)

Bits 6:0 = CC[6:0] 9-bit divider programming

Implementation of a programmable clock divider.

These bits and the CC[8:7] bits of the I2CECCR

pending on the I2C mode.

They are not cleared when the interface is disa-

bled (I2CCR.PE=0).

Refer to the Electrical Characteristics section for

the table of values (Table 70 on page 399).

Note: The programmed frequency is available

with no load on SCL and SDA pins.

I2C OWN ADDRESS REGISTER 1

(I2COAR1)

R244 - Read / Write

Reset Value: 0000 0000 (00h)

7-bit Addressing Mode

Bits 7:1 = ADD[7:1] Interface address.

These bits define the I2C bus address of the inter-

face.

They are not cleared when the interface is disa-

bled (I2CCR.PE=0).

Bit 0 = ADD0 Address direction bit.

This bit is don’t care; the interface acknowledges

either 0 or 1.

It is not cleared when the interface is disabled

(I2CCR.PE=0).

Note: Address 01h is always ignored.

10-bit Addressing Mode

Bits 7:0 = ADD[7:0] Interface address.

These are the least significant bits of the I2Cbus

address of the interface.

They are not cleared when the interface is disa-

bled (I2CCR.PE=0).

FM/SM

CC6

CC5

CC4

CC3

CC2 CC1 CC0

ADD7 ADD6 ADD5 ADD4 ADD3 ADD2 ADD1 ADD0
