ferrule with plastic sleeve

Stripping length

6 mm

Tightening torque

0.5 Nm ... 0.6 Nm

Mounting

Mounting type

THR soldering

Pin layout

Linear pinning

Drive form screw head

Slotted (L)

Processing notes

Process

Reflow/wave soldering

Moisture Sensitive Level

MSL 3

Classification temperature Tc

250 °C

Solder cycles in the reflow

3

Material specifications

Material data - contact

Note

WEEE/RoHS-compliant, free of whiskers according to IEC

60068-2-82/JEDEC JESD 201

Contact material

Cu alloy

Surface characteristics

Tin-plated

Metal surface terminal point (top layer)

Tin (5 - 7 µm Sn)

Metal surface terminal point (middle layer)

Nickel (2 - 3 µm Ni)

Metal surface soldering area (top layer)

Tin (5 - 7 µm Sn)

Metal surface soldering area (middle layer)

Nickel (2 - 3 µm Ni)

Material data - housing

Color (Housing)

black (9005)

Insulating material

PA

Insulating material group

IIIa

CTI according to IEC 60112

250 - 399

Flammability rating according to UL 94

V0

Notes

Note on application

For safe conductor connection, always adhere to a defined

tightening torque. Particularly in the case of PCB terminal blocks

with two or three positions, the individual solder pin for each

contact point cannot compensate for this. That is why the

terminal blocks must be supported during conductor connection

(held with one hand, support on the housing).
