Data Sheet

ADRF5534

SPECIFICATIONS

analog.com

Rev. A | 3 of 11

ELECTRICAL SPECIFICATIONS

VCC = 5 V, T/R = 0 V or 5 V, TCASE = 25°C, 50 Ω system, unless otherwise noted.

Table 1. Electrical Specifications

Parameter

Test Conditions/Comments

Min

Typ

Max

Unit

FREQUENCY RANGE

3.1

4.2

GHz

RECEIVE OPERATION

At 3.6 GHz, unless otherwise noted

Gain

ANT to RXOUT

35.5

dB

Gain Flatness

Over any 400 MHz bandwidth

1.5

dB

Input Return Loss

ANT port

20

dB

Output Return Loss

RXOUT port

25

dB

Reverse Isolation

RXOUT to ANT

53

dB

Term Isolation

ANT to TERM

20

dB

NF

1.3

dB

IIP3

Two-tone input power = −30 dBm per tone at 1 MHz tone spacing

−4

dBm

Input 1 dB Compression (IP1dB)

−17

dBm

Switching Speed

ANT to RXOUT, 50% of T/R to 10%, 90% of RF output

800

ns

Settling Time

ANT to RXOUT, 50% of T/R to 0.3 dB of RF output

950

ns

TRANSMIT OPERATION

At 3.6 GHz, unless otherwise noted

Insertion Loss

ANT to TERM

0.8

dB

Input Return Loss

ANT port

20

dB

Output Return Loss

TERM port

18

dB

IIP3

Two-tone input power = 30 dBm per tone at 80 MHz tone spacing

65

dBm

IP1dB

45

dBm

Input 0.1 dB Compression (IP0.1dB)

43

dBm

Switching Speed

ANT to TERM, 50% of T/R to 10%, 90% of RF output

600

ns

Settling Time

ANT to TERM, 50% of T/R to 0.3 dB of RF output

650

ns

RECOMMENDED OPERATING CONDITIONS

Supply Voltage (VCC) Range

VCC

4.75

5

5.25

V

Control Voltage Range

T/R

0

VCC

V

RF Input Power at ANT

T/R = 5 V, TC = 105°C

8 dB PAR LTE full lifetime average

37

dBm

8 dB PAR LTE single event (<10 sec) average

39

dBm

Case Temperature Range TCASE1

−40

+105

°C

Junction Temperature at Maximum TCASE1

Receive operation

145

°C

Transmit operation

135

°C

SUPPLY CURRENT (ICC)

VCC = 5 V

Receive Operation

120

mA

Transmit Operation

15

mA

DIGITAL INPUT

T/R

Low (VIL)

−0.3

0.7

V

High (VIH)

1.07

VCC

V

DIGITAL INPUT CURRENT

T/R = 5 V

5

μA

1 Measured at EPAD.
