PowerPC 440SP Embedded Processor

Revision 1.23 - Sept 26, 2006

AMCC Proprietary

Data Sheet

Signal Lists

This section contains two tables that list external signals.

Table 3 lists all the external signals in alphabetical order and shows the ball (pin) number on which the signal

appears. Multiplexed signals are shown with the default signal (following reset) not in brackets and the alternate

signal or signals in brackets.

Multiplexed signals appear alphabetically multiple times in the list—once for each signal name on the ball. The

page number listed gives the page in “Signal Functional Description” on page 56 where the signals in the indicated

interface group begin.

Table 4 on page 47 lists all the external signals in order by ball (pin) number.

Signal List—Alphabetic Order

Table 3. Signals Listed Alphabetically (Sheet 1 of 30)

Signal Name

Ball

Interface Group

Page

A1GND

B01

Power

A2GND

AG28

A1VDD

C01

A2VDD

AF28

AP0GND

AG01

AP0VDD

AF01

AP1GND

B28

AP1VDD

C28

AP2GND

T01

AP2VDD

R01

BA0

AD21

DDR SDRAM

BA1

AE20

BA2

AE25

BankSel0

T23

BankSel1

P22

CAS

AH25

ClkEn0

AE23

ClkEn1

AE24
