PowerPC 440SP Embedded Processor

Revision 1.23 - Sept 26, 2006

AMCC Proprietary

Data Sheet

Clock Test Conditions

Clock timing and switching characteristics are specified in accordance with operating

conditions shown in the table “Recommended DC Operating Conditions.” AC

specifications are characterized with VDD = 1.5V, TC = +85 °C and a 10pF test load as

shown in the figure to the right.

Table 11. DC Power Supply Loads

Parameter

Symbol

Minimum

Typical

Maximum

Unit

Notes

VDD (1.5V) active operating current

IDD

3000

OVDD (3.3V) active operating current

IODD

PxVDD (3.3V) active operating current

IPDD

730

PxVDD (1.5V) active operating current

IPDD

1600

SVDD (2.5V) active operating current

ISDD

1100

SVDD (1.8V) active operating current

ISDD

750

AxVDD (1.5V) input current

IADD

1, 2

APxVDD (1.5V) input current

IAPDD

1, 2

Notes:

1. See “Absolute Maximum Ratings” on page 63 for filter recommendations.

2. Valid only for CPU/PLB/OPB = 533.33/133.33/66.66 MHz.

Output

10pF
