STVM100
Typical operating characteristics
21/27
Figure 18.
AVDD power-up response
Figure 19.
Full scale-up response
5ms/DIV
AVDD: 5V/DIV, VDD: 5V/DIV, VOUT: 1V/DIV, VSET: 1V/DIV
VSET
VOUT
VDD
AVDD
ai13370
20µs/DIV
SCL: 5V/DIV, SDA: 5V/DIV, VOUT: 1V/DIV, VSET: 1V/DIV
ai13371
VSET
VOUT
SDA
SCL
