NYB

12

Electrical Specifications

Note: Refer to the Industrial Box PC User’s Manual (W553) for details.

* The total power consumption is the sum of the power consumption of all items that are installed in your Industrial Box PC.

To guarantee S8BA UPS operation in combination with our IPC, the specified combination of UPS and power-supply must be used.

Item

NYB2E-

@1@@@

NYB2E-

@2@@@

NYB37-

@1@@@

NYB37-

@2@@@

NYB55-

@1@@@

NYB55-

@2@@@

NYB65-

@1@@@

NYB65-

@2@@@

NYB13-

@1@@@

NYB13-

@2@@@

NYB2E-

@0@@@

NYB37-

@0@@@

NYB55-

@0@@@

NYB65-

@0@@@

NYB13-

@0@@@

CPU type

Intel® Xeon®

W-11865MRE

Intel® Core™

i7-1185GRE

Intel® Core™

i5-1145GRE

Intel® Core™

i3-1115GRE

Intel® Xeon®

W-11865MRE

Intel® Core™

i7-1185GRE

Intel® Core™

i5-1145GRE

Intel® Core™

i3-1115GRE

Rated power supply

voltage

24 VDC, non-isolated

Allowable power supply

voltage range

20.4 to 28.8 VDC

Grounding method

Ground to less than 100 Ω

Inrush current

At 24 VDC: 12 A / 6 ms max. for cold start at room temperature

Overvoltage category

JIS B3502 and IEC 61131-2: Category II

EMC immunity level

IEC 61131-2: Zone B

RTC accuracy

At ambient temperature of 55°C: -3.5 to +0.5 min error per month

At ambient temperature of 25°C: -1.5 to +1.5 min error per month

At ambient temperature of 0°C: -3 to +1 min error per month

Power button life

100,000 operations

Battery life

5 years at 25°C (for battery CJ1W-BAT01)

Fan life

8 years of continuous operation at

40°C

-

Power consumption *

-

Maximum power

consumption

including drives and

expansions

167 W

123 W

108 W

89 W

68 W

150 W

106 W

91 W

82 W

61 W

Maximum power

consumption

excluding drives and

expansions

130 W

86 W

71 W

62 W

41 W

130 W

86 W

71 W

62 W

41 W

Drives

-

HDD 320 GB

2 W

-

HDD 500 GB

2 W

-

HDD 1 TB

2 W

-

SSD SLC 32 GB

--

SSD SLC 64 GB

--

SSD MLC 128 GB

--

SSD MLC 500 GB

--

SSD 3DTLC 128 GB 1 W

-

SSD 3DTLC 256 GB 1 W

-

SSD 3DTLC 512 GB 2 W

-

SSD 3DTLC 1 TB 2 W

-

CFast MLC 64 GB

--

CFast MLC 128 GB

--

CFast MLC 256 GB

--

CFast 3DTLC 128 GB

-1 W

CFast 3DTLC 256 GB

-1 W

CFast 3DTLC 512 GB

-2 W

Expansions

-

USB

18 W max. (4 x 900 mA at 5 V)

PCIe

15 W max.

5 W max.

-

Item

NYB2E-

@1@@@

NYB2E-

@2@@@

NYB37-

@1@@@

NYB37-

@2@@@

NYB55-

@1@@@

NYB55-

@2@@@

NYB65-

@1@@@

NYB65-

@2@@@

NYB13-

@1@@@

NYB13-

@2@@@

NYB2E-

@0@@@

NYB37-

@0@@@

NYB55-

@0@@@

NYB65-

@0@@@

NYB13-

@0@@@

Minimum

power

requirements

Power supply

240 W

120 W

240 W

120 W

UPS

240 W

120 W

240 W

120 W
