NYB

Model Number Structure

The purpose of this model number legend is to provide understanding of the meaning of specifications from the model number.

Models are not available for all combinations of code numbers.

NYB

@@ - @ @ @ @ @

Series name

NYB: NY- series Industrial Box PC

Processor

1E: Intel® Xeon® E3-1515M v5

6th generation CPU with Fan Unit

for active cooling

2E: Intel® Xeon® W-11865MRE

11th generation CPU with Fan Unit

for active cooling

27: Intel® Core™ i7-7820EQ

7th generation CPU with Fan Unit

for active cooling

37: Intel® Core™ i7-1185GRE

11th generation CPU with Fan Unit

for active cooling

35: Intel® Core™ i5-7300U

7th generation CPU with fanless

cooling

55: Intel® Core™ i5-1145GRE

11th generation CPU with Fan Unit

for active cooling

65: Intel® Core™ i5-1145GRE

11th generation CPU with fanless

cooling

13: Intel® Core™ i3-1115GRE

11th generation CPU with fanless

cooling

2C: Intel® Celeron® 3965U

7th generation CPU with fanless

cooling

2A: Intel® Atom®

x5-E3940

Main memory

1: 2 GB, non-ECC

2: 4 GB, non-ECC

3: 8 GB, non-ECC

4: 16 GB, non-ECC

5: 32 GB, non-ECC

6: 64 GB, non-ECC

7: 96 GB, non-ECC

C: 8 GB, ECC

D: 16 GB, ECC

E: 32 GB, ECC

F: 64 GB, ECC

G: 96 GB, ECC

Storage

0: No disk

1: 128 GB, CFast 3DTLC

2: 256 GB, CFast 3DTLC

3: 512 GB, CFast 3DTLC

5: 64 GB, CFast MLC

6: 128 GB, CFast MLC

7: 256 GB, CFast MLC

8: 32 GB, SSD SLC

9: 64 GB, SSD SLC

Optional interface

0: No optional interface

1: RS-232C

2: DVI-D

4: DisplayPort++

6: NY Monitor Link

9: GigE LAN

Operating system

0: No operating system

3: Windows 10 IoT Enterprise 2016 LTSB - 64 bit

4: Windows 10 IoT Enterprise 2019 LTSC - 64 bit

5: Windows 10 IoT Enterprise 2021 LTSC - 64 bit

Expansion slot

0: No PCIe slot

1: PCIe slot

2: PCIe slot + HW-RAID1

C: 320 GB, HDD

D: 500 GB, HDD

E: 1 TB, HDD

F: 128 GB, SSD 3DTLC

G: 256 GB, SSD 3DTLC

H: 512 GB, SSD 3DTLC

K: 128 GB, SSD MLC

L: 256 GB, SSD MLC

M: 500 GB, SSD MLC

P: 1 TB, SSD 3DTLC
