www.sensirion.com / D1

Version 1 – June 2025

1 / 18

Datasheet ‒ STCC4 CO2 Sensor

Minimal Size. Maximize the Potential.

Highlights

•

Thermal conductivity measurement principle

•

CO2 measurement accuracy ±(100 ppm + 10%)

from 400 – 5’000 ppm

•

Digial I2C interface and calibrated output signal

•

Avg. current consumption below 100 µA in

single shot measurement mode

•

Configurable I2C address

•

Tape and reel package, reflow solderable

The STCC4 is Sensirion’s next generation miniature CO2 sensor for indoor air quality applications. Based on the

thermal conductivity sensing principle and Sensirion’s CMOSens® technology, the STCC4 enables monitoring

of CO2 gas concentration in ambient indoor air conditions at an unmatched cost-effectiveness and form factor.

SMD assembly as well as tape & reel packaging allows cost- and space-effective integration of the STCC4 for

high-volume applications. The STCC4 is 100% factory-calibrated and enables automatic on-board

compensation of the CO2 output for humidity and temperature through an external SHT4x sensor.

Functional Block Diagram
