FF0396SA1-R2000 datasheet(1/2 Pages) JAE

부품명	FF0396SA1-R2000

상세설명	0.5 mm pitch FPC connector, bottom contact, 96 pos., Standard mounting type

PDF	2 Pages

Scroll/Zoom	100%

제조업체	JAE [Japan Aviation Electronics Industry, Ltd.]

홈페이지	http://www.jae.com

Logo

1 / 2 page

FF0396SA1-R2000

Features

0.5 mm pitch FPC connector, bottom contact, 96 pos., Standard mounting type

Part Number

FF0396SA1-R2000

Status

Pending Obsolescence

Number of Positions

96 pos.

Contact Pitch (mm)

0.5 mm

Connector Type

Standard mounting type

PCB Mounted Height (mm)

2

FPC Entry Angle

Right-angle (Lower-side contact)

ZIF/ Non-ZIF/ LIF

ZIF

Applicable FPC Thickness

(mm)

0.3

Material of Contact

Copper alloy

Finish of Contact in Connecting

Area

Gold plating over Nickel

Finish of Contact in PCB

Mounting Area

Gold plating over Nickel

Packaging Type

Embossed tape packaging

Quantity in The Standard

Packaging (pieces)

2000

Product Details
