102 / 140 page  Document Number: 001-84932 Rev. *N Page 101 of 139 PSoC® 5LP: CY8C58LP Family Datasheet Figure 11-47. IDAC INL vs Input Code, Range = 255 µA, Source Mode Figure 11-48. IDAC INL vs Input Code, Range = 255 µA, Sink Mode Figure 11-49. IDAC DNL vs Input Code, Range = 255 µA, Source Mode Figure 11-50. IDAC DNL vs Input Code, Range = 255 µA, Sink Mode Figure 11-51. IDAC INL vs Temperature, Range = 255 µA, Fast Mode Figure 11-52. IDAC DNL vs Temperature, Range = 255 µA, Fast Mode 0 0.5 1 -1 -0.5 0 0 32 64 96 128 160 192 224 256 Code, 8-bit 0 0.5 1 -1 -0.5 0 0 32 64 96 128 160 192 224 256 Code, 8-bit 0 0.25 0.5 -0.5 -0.25 0 0 32 64 96 128 160 192 224 256 Code, 8-bit 0 0.25 0.5 -0.5 -0.25 0 0 32 64 96 128 160 192 224 256 Code, 8-bit 05 0.75 1 Source mode Sink mode 0 0.25 0.5 -40 -20 0 20406080 100 Temperature, °C 0.3 0.4 0.5 Source mode Sink mode 0 0.1 0.2 -40 -20 0 20406080 100 Temperature, °C |
|
