PSoC® 5LP: CY8C58LP Family

Datasheet

*H (cont.)

4698847

03/24/2015

Updated Electrical Specifications:

Updated Memory:

Updated Flash:

Updated Table 11-62:

Updated details in “Conditions” column corresponding to “Flash data retention time”

parameter.

Added Note 80 and referred the same note in last condition corresponding to “Flash data

retention time” parameter.

Updated EEPROM:

Updated Table 11-64:

Updated details in “Conditions” column corresponding to “EEPROM data retention time”

parameter.

Added Note 80 and referred the same note in last condition corresponding to “EEPROM

data retention time” parameter.

Updated Nonvolatile Latches (NVL):

Updated Table 11-66:

Updated details in “Conditions” column corresponding to “NVL data retention time”

parameter.

Added Note 81 and referred the same note in last condition corresponding to “NVL data

retention time” parameter.

Updated Clocking:

Updated Internal Main Oscillator:

Updated Table 11-80:

Replaced 85 °C with 105 °C.

Updated Figure 11-83.

Updated Ordering Information:

Updated Table 12-1:

Updated part numbers.

Updated Part Numbering Conventions:

Added “Q: Extended” as sub bullet under “g: Temperature Range”.

Updated Packaging:

Updated Table 13-1:

Changed maximum value of TA parameter from 85 °C to 105 °C.

Changed maximum value of TJ parameter from 100 °C to 120 °C.

Updated :

spec 001-88034 – Changed revision from ** to *A.

4839323

07/15/2015

Added reference to code examples in More Information.

Updated typ value of TWRITE from 2 to 10 in EEPROM AC specs table.

Changed “Device supply for USB operation" to "Device supply (VDDD) for USB operation"

in USB DC Specifications.

Clarified power supply sequencing and margin for VDDA and VDDD.

Updated Serial Wire Debug Interface with limitations of debugging on Port 15.

Updated Delta-sigma ADC DC Specifications

Document History Page (continued)

Description Title: PSoC® 5LP: CY8C58LP Family Datasheet Programmable System-on-Chip (PSoC®)

Document Number: 001-84932

Revision

ECN

Submission

Date

Description of Change
