Page <2>

V1.0

02/04/20

PVC Insulating Tubing

Newark.com/multicomp-pro

Farnell.com/multicomp-pro

Element14.com/multicomp-pro

Description

AWG

Size

Nominal I.D

Nominal Wall

Thickness

Spool

Size

(Feet)

Part Number

Inches

(mm)

Inches

(mm)

Colour Black

Colour Clear

PVC Insulating

Tubing

24

0.022

0.56

0.012

0.30

100

PVI-S24-1100-BLK

PVI-S24-1100-CLR

22

0.027

0.69

PVI-S22-1100-BLK

PVI-S22-1100-CLR

20

0.034

0.86

0.016

0.41

PVI-S20-1100-BLK

PVI-S20-1100-CLR

19

0.038

0.97

PVI-S19-1100-BLK

N/A

18

0.042

1.07

PVI-S18-1100-BLK

PVI-S18-1100-CLR

17

0.047

1.19

PVI-S17-1100-BLK

PVI-S17-1100-CLR

16

0.053

1.35

PVI-S16-1100-BLK

PVI-S16-1100-CLR

15

0.059

1.50

PVI-S15-1100-BLK

PVI-S15-1100-CLR

14

0.066

1.68

PVI-S14-1100-BLK

PVI-S14-1100-CLR

13

0.076

1.93

PVI-S13-1100-BLK

PVI-S13-1100-CLR

12

0.085

2.16

PVI-S12-1100-BLK

PVI-S12-1100-CLR

11

0.095

2.41

PVI-S11-1100-BLK

PVI-S11-1100-CLR

10

0.106

2.69

PVI-S10-1100-BLK

N/A

9

0.118

3.00

0.020

0.51

PVI-S09-1100-BLK

8

0.133

3.38

PVI-S08-1100-BLK

PVI-S08-1100-CLR

7

0.148

3.76

PVI-S07-1100-BLK

PVI-S07-1100-CLR

6

0.166

4.22

PVI-S06-1100-BLK

PVI-S06-1100-CLR

5

0.186

4.72

PVI-S05-1100-BLK

PVI-S05-1100-CLR

4

0.208

5.28

PVI-S04-1100-BLK

PVI-S04-1100-CLR

3

0.234

5.94

PVI-S03-1100-BLK

PVI-S03-1100-CLR

2

0.263

6.68

PVI-S02-1100-BLK

PVI-S02-1100-CLR

1

0.294

7.47

PVI-S01-1100-BLK

N/A

5/16"

0.313

7.95

0.025

0.64

PVI-020-1100-BLK

PVI-020-1100-CLR

0

0.330

8.38

PVI-S00-1100-BLK

N/A

3/8"

0.375

9.53

PVI-024-1100-BLK

PVI-024-1100-CLR

7/16"

0.438

11.13

PVI-028-1100-BLK

N/A

1/2"

0.500

12.70

PVI-032-1100-BLK

5/8"

0.625

15.88

0.030

0.76

PVI-040-1100-BLK

3/4”

0.750

19.05

0.035

0.89

50

PVI-048-1050-BLK

1"

1.000

25.40

PVI-064-1050-BLK

2"

2.000

50.80

0.06

1.52

PVI-128-1050-BLK

9

0.118

3.00

0.020

0.51

500

PVI-S09-1500-BLK

18

0.042

1.07

0.016

0.41

500

N/A

PVI-S18-1500-CLR

Part Number Table
