background image
AD822
Rev. G | Page 11 of 28
Parameter
Conditions
Typ
Unit
OUTPUT CHARACTERISTICS
Output Saturation Voltage1
VOL − VEE
ISINK = 20 μA
5
mV
VCC − VOH
ISOURCE = 20 μA
10
mV
VOL − VEE
ISINK = 2 mA
40
mV
VCC − VOH
ISOURCE = 2 mA
80
mV
VOL − VEE
ISINK = 10 mA
200
mV
VCC − VOH
ISOURCE = 10 mA
500
mV
Capacitive Load Drive
350
pF
POWER SUPPLY
Quiescent Current
1.24
mA
TMIN to TMAX
Power Supply Rejection
VS+ = 3 V to 15 V
80
dB
TMIN to TMAX
1 VOL − VEE is defined as the difference between the lowest possible output voltage (VOL) and the negative voltage supply rail (VEE). VCC − VOH is defined as the difference
between the highest possible output voltage (VOH) and the positive supply voltage (VCC). Specifications are TMIN to TMAX.
