AD822
Rev. G | Page 17 of 28
FREQUENCY (Hz)
–70
–140
300
1M
1k
3k
10k
30k
100k
300k
–80
–100
–110
–120
–130
–90
Figure 28. Crosstalk vs. Frequency
VIN
RL
VOUT
100pF
8
+VS
0.01µF
4
0.01µF
1/2
AD822
+
–
Figure 29. Unity Gain Follower
0%
100
90
10
5V
10µs
Figure 30. 20 V p-p, 25 kHz Sine Wave Input; Unity Gain Follower; VS = ±15 V,
RL = 600 Ω
+Vs
20V p-p
2
3
8
5
6
20kΩ
2.2kΩ
5kΩ
5kΩ
VOUT
CROSS TALK = 20 log
VOUT
10VIN
0.1µF
1µF
0.1µF
1µF
–Vs
VIN
1/2
AD822
1
1/2
AD822
7
Figure 31. Crosstalk Test Circuit
0%
100
90
10
5V
5µs
Figure 32. Large Signal Response Unity Gain Follower; VS = ±15 V, RL = 10 kΩ
10
0%
100
90
10mV
500ns
Figure 33. Small Signal Response Unity Gain Follower; VS =±15 V, RL = 10 kΩ
GND
10
0%
100
90
1V
2µs
Figure 34. VS = 5 V, 0 V; Unity Gain Follower Response to 0 V to 4 V Step
4
VIN
RL
VOUT
100pF
8
+VS
0.01µF
1/2
AD822
+
–
Figure 35. Unity Gain Follower
