OSRAM High Bright PowerFlex LED Strips 7.5mm LED Pitch

ILX-E507-xx10-3240-SD2xx

The PowerFlex range are densely populated, high bright, flexible LED strips using the OSRAM DURIS E5/E2825 LED at

its heart. Unlike standard flexible LED strips, the ILX range of strips from ILS incorporate constant current drivers, protection

diodes and the latest 3M thermal tape. This combination gives unparalleled performance with brightness in excess of 3000

lumens per metre whilst still achieving 50,000 hours working life. Combined with a full range of accessories including

extrusions and connectors, the ILX family of flexible LED reels finally offers a solution for the industrial as well as consumer

markets.

CONTENTS

Applications

page 2

Technical Features

page 2

Product Options

page 3

Min and max value table

page 3

Technical Drawings

page 5

LED Radiation Diagram

page 5

Heatsink Options

page 6

Power Supply Options

page 7-8

Thermal Interface Material Options

page 9

Important Information and Precautions

page 9

Safety Information

page 10
