Table 34 Maximum power consumption in shutdown mode
Symbol
Parameter
Condition
Voltage (TA=105℃)
Unit
3.3V
5V
5.5V
IDD
Supply
current in
halt mode
Running mode of Flash,
HIRC as clock source after wake up
30.65
32.39
33.77
µA
Flash power-down mode,
HIRC as clock source after wake up
24.70
26.72
27.44
Table 35 Typical value of peripheral power consumption (VDD=5V,TA=25℃)
Symbol
Parameter
16MHz
48MHz
Unit
IDD(TMR1)
TMR1 supply current
98
300
µA
IDD(TMR1A)
TMR1A supply current
58
170
IDD(TMR2)
TMR2 supply current
56
168
IDD(TMR4)
TMR4 timer supply current
15
46
IDD(USART1)
USART1 supply current
56
168
IDD(USART2)
USART2 supply current
100
310
IDD(USART3)
USART3 supply current
55
170
IDD(SPI)
SPI supply current
23
68
IDD(I2C)
I2C supply current
37
110
IDD(ADC1)
Supply current during ADC1 conversion
290
680
I/O port characteristics
Table 36 I/O static characteristics and AC characteristics (VDD=2.4~5.5V, TA=-40~105°C)
Symbol
Parameter
Condition
Min
Typ
Max
Unit
VIL
Input low level
voltage
VDD=5V
-0.3
-
0.3xVDD
V
VIH
Input high level
voltage
0.7xVDD
-
VDD+0.3
Vhys
Voltage
hysteresis
-
700
-
mV
Rpu
pull up resistor
VDD=5V,VIN=VSS
55
63
66
kΩ
tR,tF
Rise and fall
time (10%-90%)
Fast I/O port with
load capacitance of
50pF
-
-
17
nS
Standard and high
sinkI/O port, load
capacitance 50pF
-
-
17
Ilkg
Digital input
leakage current
VSS≤VIN≤VDD
-
-
±1
μA
